CDUB-SVN002B-EN 27
Wiring Diagrams
Notes:
All of the schematic wiring diagrams displayed within
this section
of the installation manual are proprietary.
These diagrams shall not be copied or their contents
disclosed to outside parties without the written
consent of Trane.
The following hazard notifications apply
to all of the
electrical circuits depicted in each of the schematic
wiring diagrams included within this section of the
installation manual.
WARNING
Hazardous Voltage w/Capacitors!
Failure to disconnect power and discharge capacitors
before servicing could result in death or serious injury.
Disconnect all electric power, including r
emote
disconnects and discharge all motor start/run
capacitors before servicing. Follow proper lockout/
tagout procedures to ensure the power cannot be
inadvertently energized. For variable frequency drives
or other energy storing components provided by Trane
or others, refer to the appropriate manufacturer’s
literature for allowable waiting periods for discharge
of capacitors. Verify with a CAT III or IV voltmeter
rated per NFPA 70E that all capacitors have
discharged.
WARNING
Ground Wire!
Failure to follow this instruction could result in death
or serious injuries. All field-installed wiring must be
completed by qualified personnel. All field-installed
wiring must comply with NEC and applicable local
codes.
NOTICE
Use Copper Conductors Only!
Failure to use copper conductors could result in
equipment damage. Unit terminals are not designed to
accept other types of conductors.
Table 3. Package and diagram matrix
Description CADE Upgrade Kit Literature Diagram
UC800-CDUA CDUA 018534960100 and 018535010100 5071-2800
5071-2795
5071-2794
UC800-CVRE CVRE 018534960100 and 018535020100 5071-2801
5071-2799
5071-2794
UC800-CTV-SIM SIMP 018534960100 and 018535040100 5071-2808 5071-2805
UC800-CTV-DUP DUPL 018534960100 and 018535040100 5071-2808 5071-2805
UC800-CVHS CVHS 018534960100 and 018535040100 5071-2808 5071-2805
UC800-CVHM CVHM 018534960100 and 018535040100 5071-2808 5071-2805
UC800-AGILITY HDWA 018534960100 and 018535040100 5071-2807 5071-2802
UC800-ECTV ECTV 018534960100 and 018535050100 5071-2809 5071-2806
