Trane GEHE - Right Return;Top Supply

Unit Dimensions and Weights
WSHP-SVX01L-EN 21
Figure 14. Right return/top supply: GEVE—“A” and later design sequence; EXV—”A” and later design sequence)
Note: During installation, apply a typical 36 in. access at the front service access panel.
C
A
3 5/8"3 5/8"
(92)(92)
8 3/4"8 3/4"
(222)(222)
LO VOLTLO VOLT
HI VOLTHI VOLT
W.I.W.I.
DRAINDRAIN
W.O.W.O.
3 5/8"3 5/8"
(92)(92)
12"12"
(305)(305)
H
B
D
L
F
J M
E
D
K
9 1/2"9 1/2"
(241)(241)
G
FRONT
FRONT RIGHT SIDERIGHT SIDE
TOPTOP
LEFT SIDELEFT SIDE
BLOWER BLOWER
ACCESSACCESS
COMP/CONTROL COMP/CONTROL
ACCESSACCESS
Table 11. Right return/top supply: GEVE—“A” and later design sequence; EXV—“A” and later design sequence
GEV Unit A B C D E F G H J K L M
W.I.
NPTI
W.O.
NPTI
Drain
FPT
006-015
19-1/2
(495)
31-1/4
(794)
21-1/2
(546)
11-1/2
(292)
4
(102)
5-3/4
(146)
9-1/2
(241)
15
(381)
17
(432)
6-7/8
(175)
8
(203)
3/4
(19)
1/2
(13)
1/2
(13)
3/4
(19)
018, 024,
030, 032, 040
21-1/2
(546)
39-1/4
(997)
21-1/2
(546)
13-1/2
(343)
4
(102)
4
(1021)
9-1/2
(241)
23-3/4
(603)
17 (432)
8-1/4
(368)
9-3/4
(248)
3/4
(19)
3/4
(19)
3/4
(19)
3/4
(19)
11-3/8
(289)
036, 042
24-1/2
(622)
41-7/8
(1064)
26-1/2
(673)
18 (457)
3-1/4
(83)
5-3/4
(146)
9-1/2
(241)
19
(483)
23 (584)
10-1/2
(267)
13-1/2
(343)
1-3/4
(19)
3/4
(19)
3/4
(19)
3/4
(19)
Std-048
26-1/2
(673)
46-7/8
(1191)
30-1/2
(775)
18 (457)
4-1/4
(108)
2
(51)
9-1/2
(241)
29
(737)
27-7/8
(708)
13-7/8
(352)
13-7/8
(352)
1/2
(13)
1
(25)
1
(25)
3/4
(19)
Hi-048, 060
26-1/2
(673)
46-7/8
(1191)
30-1/2
(775)
18 (457)
4-1/4
(108)
2
(51)
9-1/2
(241)
29
(737)
27-7/8
(708)
13-1/8
(333)
11-3/8
(289)
1/2
(13)
1
(25)
1
(25)
3/4
(19)
EXV Unit A B C D E F G H J K L M
W.I.
NPTI
W.O.
NPTI
Drain
FPT
018-024
21-1/2
(546)
39-1/4
(997)
21-1/2
(546)
13-1/2
(343)
4 (102) 4 (1021)
9-1/2
(241)
23-3/4
(603)
17 (432)
8-1/4
(368)
11-3/8
(289)
3/4
(19)
2
(51)
3/4
(19)
3/4
(19)
030-036
24-1/2
(622)
41-7/8
(1064)
26-1/2
(673)
18
(457)
3-1/4
(83)
5-3/4
(146)
9-1/2
(241)
19 (483) 23 (584)
10-1/2
(267)
13-1/2
(343)
1-3/4
(19)
0
3/4
(19)
3/4
(19)
042-060
26-1/2
(673)
46-7/8
(1191)
30-1/2
(775)
18 (457)
4-1/4
(108)
2
(51)
9-1/2
(241)
29 (737)
27-7/8
(708)
13-7/8
(352)
11-3/8
(289)
1/2
(13)
3-1/2
(89)
1
(25.4)
1
(25.4)
070
26-1/2
(673)
50-7/8
(1292)
30-1/2
(775)
18 (457)
4-1/4
(108)
2
(51)
9-1/2
(241)
29 (737)
27-7/8
(708)
13-1/8
(333)
11-3/8
(289)
1/2
(13)
3-1/2
(89)
1
(25.4)
1
(25.4)
Note: All dimensions are in inches followed by millimeters in parenthesis.
