Trane GEHE - Left Return;Right Supply

Unit Dimensions and Weights
WSHP-SVX01L-EN 25
Figure 18. GEH 6-10 tons (072-120) 60 Hz; GEH 6-7½ tons (072-090) 50 Hz - left return/right supply
20"
(508)
SERVICE
CLEARANCE
79"
(2007)
74 1/2"
(1892)
1 3/4"
(44)
36"
(914)
SERVICE
CLEARANCE
4 5/8"
(117)
36"
(914)
40 5/8"
(1032)
7 5/8"
(194)
18 3/8"
(467)
81"
(2057)
85"
(2159)
1 1/4"
(32)
24 3/4"
(629)
BLOWERACCESS
PANEL
3 1/8"
(79)
4 7/8"
(124)
1"
(25.4)
5/8"
(16)
18 3/4"
(476)
14 1/2"
(368)
DRAIN CONNECTION
1/2" (22) SCHEDULE 40 PVC
1 1/4"
(32)
C
B
A
W.O. "D" NPTI
W.I. "D" NPTI
24VOLT
1 1/8" (28.6) DIA.
HIGHVOLTAGE
7/8" (22.2) DIA.
23 1/4"
(591)
16 1/2"
(419)
2 1/4"
(57)
6 1/2"
(165)
1 1/2"
(38)
TOPVIEW
BACK SIDE
LEFT SIDE
RETURN AIR
OPENING
1" (25.4) DIA.
MOUNTING HOLE
4X'S
SUPPLY OPENING
1" (25.4) DUCT FLANGE
Table 15. GEH 6-10 tons (072-120) 60 Hz; GEH 6-7½ tons (072-090) 50 Hz—left return/right supply
GEH (60 Hz) GEH (50 Hz) A B C D
072 —
36-1/8 in.
(917 mm)
17 in.
(432 mm)
8 in.
(203 mm)
1-1/4 in.
(32 mm)
090 072
36-1/8 in.
(917 mm)
13-3/4 in.
(349 mm)
7-3/4 in.
(197 mm)
1-1/4 in.
(32 mm)
120 090
36-1/8 in.
(917 mm)
13 in.
(330 mm)
7-1/4 in.
(184 mm)
1-1/2 in.
(38 mm)
