Trane GEHE - GEV 6-10 T 60 Hz; 6 and 7,5 Ton 50 Hz-Back Return;Front Supply

Unit Dimensions and Weights
WSHP-SVX01L-EN 33
Figure 26. GEV 6–10 tons (072-120) 60 Hz; 6 and 7½ ton (072 and 090) 50 Hz—back return/front supply
(a)
(a)NEC requires that the GEV072-300 front return must be a non-ducted return.
1" (25.4)
20"
(508)
SERVICE
CLEARANCE
39 5/8"
(1006)
ACCESS PANEL FOR
SHEAVES AND BELTS
13 1/8"
(333)
15 3/4
(400)
42"
(1067)
4 7/8"
(124)
1 1/8"
(29)
36 1/4"
(921)
31 3/8"
(797)
36"
(914)
SERVICE
CLEARANCE
62 5/8"
(1591)
46 1/2"
(1181)
B
W.O. "C" NPTI
DRAIN 3/4" NPTI
A
11 1/2"
(292)
1 7/8"
(48)
W.I. "C" NPTI
HIGH VOLTAGE
7/8" (22.2) DIA.
1 5/8"
(41)
5"
(127)
15"
(381)
38 7/8"
(987)
22 3/8"
(568)
3/4"
(19)
SUPPLY OPENING
1" (25.4) DUCT FLANGE
RETURN AIR
OPENING
24 VOLT
1 1/8" (28.6)
13 1/2"
(343)
Table 19. GEV 6–10 tons (072-120) 60 Hz; 6 and 7½ ton (072 and 090) 50 Hz—back return/front supply
Unit (60 Hz) Unit (50 Hz) A B C
6 ton —
6-5/8 in.
(168 mm)
18-3/8 in.
(467 mm)
1-1/4 in.
(32 mm)
7½ ton 6 ton
6-5/8 in.
(168 mm)
18-3/8 in.
(403 mm)
1-1/4 in.
(32 mm)
10 ton 7½ ton
6-1/2 in.
(165 mm)
18-1/2 in.
(470 mm)
1-1/2 in.
(38 mm)
