Trane GEHE - GEH 12,5-15 T 60 Hz, L Return;Geh 10-12,5 T 50 Hz, L Return, Waterside

Unit Dimensions and Weights
48 WSHP-SVX01L-EN
Figure 41. GEH 12½-15 tons (150-180) 60 Hz, left return; GEH 10-12½ tons (120-150) 50 Hz, left return, waterside
economizer
(a)(b)
(a)Entering water is on the AB port.
(b)Field piping required on waterside economizer.
27 1/8"
(689)
9 7/8"
(251)
42"
(1067)
56 1/2"
(1435)
1 5/8" (42) OD COPPER TO
FIELD SUPPLY PIPING
18 1/2"
(470)
29 3/4"
(756)
2 1/4"
(57)
12"
(305)
5 3/8"
(137)
1 1/2" (38) NPTI FOR
FIELD RETURN PIPING
