Trane GEHE - GEH 6-10 T 60 Hz, L Return;Geh 6-7,5 T50 Hz, L Return, Waterside Econom

Unit Dimensions and Weights
46 WSHP-SVX01L-EN
Figure 39. GEH 6-10 tons (072-120) 60 Hz, left return; GEH 6-7½ tons (072-090) 50 Hz, left return, waterside economizer
(a)(b)
(a)Entering water is on the AB port.
(b)Field piping required on waterside economizer.
C
9 7/8"
(251)
36"
(914)
50 5/8"
(1286)
"B" OD COPPER TO
FIELD SUPPLY PIPING
18 1/2"
(470)
24 3/4"
(629)
1 1/4"
(32)
D
E
"A" NPTI FOR
FIELD RETURN PIPING
Table 27. GEH 6-10 tons (072-120) 60 Hz, left return; GEH 6-7½ tons (072-090) 50 Hz, left return, waterside economizer
GEH (60 Hz) GEH (50 Hz) A B C D E
072-090 072
1-1/4
(32)
1-3/8
(35)
31
(787)
9-7/8
(251)
3-7/8
(98)
120 090
1-1/2
(38)
1-5/8
(41)
30-3/4
(781)
12-1/2
(318)
4-1/2
(114)
Note: All dimensions are in inches followed by millimeters in parenthesis.
