Trane GEHE - Page 70

Electrical Data
70 WSHP-SVX01L-EN
GEVE032
GEVE032 208/60/1 18.3 14.7 72.5 1 23.0 3.60 1/2 1 21.98 35 0.0 0.0
GEVE032 208/60/1 23.3 14.7 72.5 1 23.0 3.60 1/2 1 29.14 35 4.1 19.7
GEVE032 230/60/1 18.3 14.7 72.5 1 23.0 3.60 1/2 1 21.98 35 0.0 0.0
GEVE032 230/60/1 25.3 14.7 72.5 1 23.0 3.60 1/2 1 31.67 35 5.0 21.7
GEVE032 265/60/1 15.3 12.5 61.0 1 19.5 2.77 1/2 1 18.40 30 0.0 0.0
GEVE032 265/60/1 27.7 12.5 61.0 1 19.5 2.77 1/2 1 34.59 35 6.6 24.9
GEVE032 208/60/3 14.0 10.4 63.0 1 16.3 3.60 1/2 1 16.60 25 0.0 0.0
GEVE032 208/60/3 15.0 10.4 63.0 1 16.3 3.60 1/2 1 18.73 25 4.1 11.4
GEVE032 230/60/3 14.0 10.4 63.0 1 16.3 3.60 1/2 1 16.60 25 0.0 0.0
GEVE032 230/60/3 16.2 10.4 63.0 1 16.3 3.60 1/2 1 20.19 25 5.0 12.6
GEVE032 460/60/3 6.2 4.5 31.0 1 7.0 1.70 1/2 1 7.33 15 0.0 0.0
GEVE032 460/60/3 10.0 4.5 31.0 1 7.0 1.70 1/2 1 12.48 15 6.6 8.3
GEHE/GEVE
036 208/60/1 20.3 16.7 79.0 1 26.0 3.60 1/2 1 24.48 40 0.0 0.0
036 208/60/1 27.2 16.7 79.0 1 26.0 3.60 1/2 1 33.95 40 4.9 23.6
036 230/60/1 20.3 16.7 79.0 1 26.0 3.60 1/2 1 24.48 40 0.0 0.0
036 230/60/1 29.7 16.7 79.0 1 26.0 3.60 1/2 1 37.11 40 6.0 26.1
036 265/60/1 16.3 13.5 72.0 1 21.0 2.77 1/2 1 19.65 30 0.0 0.0
036 265/60/1 32.8 13.5 72.0 1 21.0 2.77 1/2 1 40.96 45 8.0 30.0
036 208/60/3 14.0 10.4 73.0 1 16.3 3.60 1/2 1 16.60 25 0.0 0.0
036 208/60/3 17.2 10.4 73.0 1 16.3 3.60 1/2 1 21.50 25 4.9 13.6
036 230/60/3 14.0 10.4 73.0 1 16.3 3.60 1/2 1 16.60 25 0.0 0.0
036 230/60/3 18.7 10.4 73.0 1 16.3 3.60 1/2 1 23.33 25 6.0 15.1
036 380-415/50/3 7.7 6.0 44.0 1 9.3 1.70 1/2 1 9.20 15 0.0 0.0
036 380-415/50/3 11.6 6.0 44.0 1 9.3 1.70 1/2 1 14.56 15 7.2 9.9
036 460/60/3 7.5 5.8 38.0 1 9.0 1.70 1/2 1 8.95 15 0.0 0.0
036 460/60/3 11.7 5.8 38.0 1 9.0 1.70 1/2 1 14.60 15 8.0 10.0
GEVE040
GEVE040 208/60/1 22.2 18.6 105.0 1 29.0 3.60 1/2 1 26.85 45 0.0 0.0
GEVE040 208/60/1 29.6 18.6 105.0 1 29.0 3.60 1/2 1 36.95 45 5.4 26.0
GEVE040 230/60/1 22.2 18.6 105.0 1 29.0 3.60 1/2 1 26.85 45 0.0 0.0
GEVE040 230/60/1 32.3 18.6 105.0 1 29.0 3.60 1/2 1 40.37 45 6.6 28.7
GEVE040 265/60/1 20.7 17.9 98.0 1 28.0 2.77 1/2 1 25.15 40 0.0 0.0
GEVE040 265/60/1 36.0 17.9 98.0 1 28.0 2.77 1/2 1 44.97 45 8.8 33.2
GEVE040 208/60/3 17.1 13.5 88.0 1 21.0 3.60 1/2 1 20.48 30 0.0 0.0
GEVE040 208/60/3 18.6 13.5 88.0 1 21.0 3.60 1/2 1 23.24 30 5.4 15.0
GEVE040 230/60/3 17.1 13.5 88.0 1 21.0 3.60 1/2 1 20.48 30 0.0 0.0
GEVE040 230/60/3 20.2 13.5 88.0 1 21.0 3.60 1/2 1 25.21 30 6.6 16.6
GEVE040 460/60/3 8.1 6.4 39.0 1 10.0 1.70 1/2 1 9.70 15 0.0 0.0
GEVE040 460/60/3 12.7 6.4 39.0 1 10.0 1.70 1/2 1 15.93 20 8.8 11.0
Table 44. Electrical data: Standard static motors, ½–5 tons (continued)
Model
No. Volts
Total
Unit
FLA
Comp
RLA
(ea)
Comp
LRA
(ea)
No. of
Comp.
Cmp
MCC
Blower
Motor
FLA
Blower
Motor
hp
Fan
Motor
Num.
Minimum
Circuit
Ampacity
Maximum
Overcurrent
Protective
Device
Electric
Heat
kW
Electric
Heat
Amps
