Trane GEHE - Page 96

Start-Up
96 WSHP-SVX01L-EN
EXHF070
(60 Hz)
35 12.3 85-98 296-373 6-7 20-25
35 15.4 87-100 298-375 5-6 20-26
45 12.3 132-151 167-216 12-16 22-28 100-115 322-403 7-8 23-29
45 15.4 132-151 161-209 10-12 22-28 103-118 324-406 5-7 23-30
55 12.3 132-152 195-252 12-15 21-27 117-134 341-427 8-10 26-33
55 15.4 132-152 188-244 10-12 21-27 120-138 343-431 6-8 26-34
68 12.3 134-154 235-304 12-15 21-27 141-162 374-468 9-12 30-39
68 15.4 134-154 228-294 10-12 21-27 145-167 378-473 8-10 31-39
75 12.3 135-155 259-335 12-15 21-26 155-179 390-488 10-13 33-42
75 15.4 135-155 252-325 9-12 21-26 160-185 395-494 8-10 34-43
86 12.3 136-157 297-384 12-15 20-26 180-207 418-524 11-15 37-47
86 15.4 136-157 289-374 9-12 20-26 186-215 423-530 9-12 38-48
95 12.3 138-159 334-431 11-15 20-25
95 15.4 138-159 326-421 9-12 20-25
EXVF018
(60 Hz)
35 3.3 91-104 280-353 6-8 21-26
35 4.2 92-106 281-355 5-6 21-27
45 3.3 142-163 158-206 11-15 23-29 106-122 301-379 7-9 24-30
45 4.2 141-163 151-197 9-11 23-29 108-125 304-383 6-7 24-31
55 3.3 141-162 187-243 12-15 23-29 123-142 319-401 8-10 27-34
55 4.2 141-162 179-233 9-12 23-29 126-145 322-405 6-8 27-35
68 3.3 141-163 227-295 12-15 22-28 149-171 352-441 10-12 31-39
68 4.2 141-163 219-284 9-12 22-28 153-176 356-446 8-10 32-40
75 3.3 142-163 253-328 12-15 21-27 165-189 364-456 10-13 33-42
75 4.2 142-163 245-317 9-12 21-27 170-196 368-461 8-10 34-43
86 3.3 143-165 298-385 12-15 20-26 192-221 383-480 11-14 36-46
86 4.2 143-164 288-372 9-12 20-26 199-229 386-484 9-11 37-47
95 3.3 144-166 339-437 12-15 19-24
95 4.2 144-166 329-424 9-12 19-25
EXVF024
(60 Hz)
35 4.4 85-98 278-351 6-7 21-27
35 5.6 87-100 280-353 4-6 22-28
45 4.4 136-156 165-215 12-15 23-30 100-115 299-375 7-8 25-32
45 5.6 135-156 158-206 10-12 23-30 103-118 301-378 5-7 26-32
55 4.4 137-158 193-251 12-15 22-28 117-134 314-395 8-10 29-36
55 5.6 137-157 186-241 9-12 22-29 120-138 318-399 6-8 29-37
68 4.4 138-159 234-304 12-15 21-27 141-162 346-433 9-11 33-42
68 5.6 138-159 226-293 9-12 22-28 145-167 350-438 7-9 33-42
75 4.4 139-160 260-336 12-15 21-27 155-179 358-449 10-12 35-44
75 5.6 139-160 251-325 9-12 21-27 161-185 363-454 8-10 35-45
86 4.4 141-162 303-391 12-15 20-26 180-207 380-476 11-14 37-47
86 5.6 141-162 294-379 9-12 20-26 187-215 385-482 9-11 38-48
95 4.4 142-164 343-442 11-15 19-25
95 5.6 142-163 334-430 9-11 20-25
Table 50. Operating pressures in cooling/heating for EX units (continued)
Operating Data
Cooling Heating
Model
Entering
water
temp (ºF)
Water
flow
(GPM)
Suction
pressure
(psig)
Discharge
pressure
(psig)
Water
temp rise
(ºF)
Air temp
drop
(ºF DB)
Suction
pressure
(psig)
Discharge
pressure
(psig)
Water
Temp drop
(ºF)
Air temp
rise
(ºF DB)
