Trane IntelliPak 2 - Weights

22
RT-SVX073A-EN
Weights
Table 9. Approximate operating weights (lbs.)
Air-Cooled Units
Nominal Tons
Unit
(Minimum)
Roof Curb
(Minimum)
90 14973 907
105 16411 907
120 18447 1040
130 18467 1040
150 19176 1040
Notes:
1. Weights shown include the following
features: No heat, standard evap capacity
coils, fixed speed compressors, 0-25%
outside air, 2" throwaway filters, low CFM
supply fan, minimum supply motor sizes, no
return or exhaust fan.
2. Weights shown represent approximate
minimum operating weights. To calculate
weight for a specific unit configuration,
utilize TOPSS or contact the local Trane
sales representative. Weight outputs have a
+ 10% accuracy. ACTUAL WEIGHTS ARE
STAMPED ON THE UNIT NAMEPLATE.
Table 10. Component weights
90 105 120 130 150
Size
Weight
Size
Weight
Size
Weight
Size
Weight
Size
Weight
Refrigeration
Compressor Assy. - Fixed capacity compressors
- 1126 - 1630 - 1642 - 1666 - 1666
Compressor Assy. - eFlexTM Variable speed
- 1479 - 1503 - 1626 - 1524 - 1786
Air-Cooled Condensing Coil (Al)
- 1173 - 1421 - 1485 - 1485 - 1485
Evap Coil - Std. Cap
- 1034 - 1300 - 1892 - 1892 - 2564
Evap Coil - Hi. Cap.
- 1382 - 1462 - 2564 - 2564 -
Reheat Coil & Tubing
- 292 - 294 - 367 - 367 - 367
Replaceable Core Filter Driers
- 26 - 25 - 35 - 35 - 35
HGBP - 46 - 49 - 53 - 53 - 53
Supply Fan Assembly
Supply Fan & Fan Board Assy. - Low CFM
25" 1159 32" 1361 32" 1361 32" 1361 32" 1361
Supply Fan & Fan Board Assy. - Std. CFM
36" 1490 36" 1490 40" 1653 40" 1653 40" 1653
Belt Guard - 116 - 116 - 116 - 116 - 116
Supply VFD (50 hp and below)
- 233 - 233 - 233 - 233 - 233
Supply VFD (60-100 hp)
- 284 - 284 - 284 - 284 - 284
Supply Fan Motor - 15 hp
- 181 - 181 - 181 - 181 - 181
Supply Fan Motor - 20 hp
- 206 - 206 - 206 - 206 - 206
Supply Fan Motor - 25 hp
- 358 - 358 - 358 - 358 - 358
Supply Fan Motor - 30 hp
- 413 - 413 - 413 - 413 - 413
Supply Fan Motor - 40 hp
- 495 - 495 - 495 - 495 - 495
Supply Fan Motor - 50 hp
- 604 - 604 - 604 - 604 - 604
Supply Fan Motor - 60 hp
- 776 - 776 - 776 - 776 - 776
Supply Fan Motor - 75 hp
- 879 - 879 - 879 - 879 - 879
Supply Fan Motor - 100 hp
- 1102 - 1102 - 1102 - 1102 - 1102
Return/Relief Fan Assembly
Return Fan & Dampers - Low CFM
36" 2294 36" 2294 36" 2294 36" 2294 36" 2294
Return Fan & Dampers - Std. CFM
40" 2343 40" 2343 44" 2445 44" 2445 44" 2445
Exhaust Fan & Dampers - Low CFM
25" 889 28" 979 28" 979 28" 979 28" 979
Exhaust Fan & Dampers - Std. CFM
28" 979 32" 1429 32" 1429 32" 1429 32" 1429
Belt Guard - 119 - 119 - 119 - 119 - 119
