Figure 12. Typical unit rigging—two-piece unit with two lifting lugs per side
12 ft min
12 ft min
Condenser with two
lifting lugs per side
Air handler with two
lifting lugs per side
Turnbuckle or
Chain Adjustment
for each lug
Note: Turnbuckle or chain adjustment required for each lifting point.
