Trane PIC - Page 37

Operation
37BAS-SVX08D-E4
30070 69 Compressor A operating mode None
30071 70 Compressor B operating mode None
30072 71 Compressor C operating mode None
30073 72 Compressor D operating mode None
30074 73 Slave EXV software revision level None
30075 74 COMM3 framing errors None
30076 75 COMM3 UART buffer overrun errors None
30077 76 COMM3 bad zero byte errors None
30078 77 COMM3 bad serial function code errors None
30079 78 COMM3 write outside of write buffer errors None
30080 79 COMM3 CRC errors None
30081 80 COMM3 message time-out errors None
30082 81 IPC bad CSR token errors None
30083 82 IPC UART buffer overrun/framing errors None
30084 83 IPC CRC errors None
30085 84 IPC message time-out errors None
30086 85 IPC communication state at time of last time-out error None
30087 86 Circuit 1 saturated evap refrigerant press Pressure
30088 87 Circuit 2 saturated evap refrigerant press Pressure
30089 88 Circuit 1 saturated cond refrigerant press Pressure
30090 89 Circuit 2 saturated cond refrigerant press Pressure
Data
Type
Offset Point DescriptionFunction
Modbus
Index
Analog
Inputs
4
Unit
Table 14 - Continued
