Operation
BAS-SVX08D-E436
Data
Type
Offset Point DescriptionFunction
Modbus
Index
30022 21 Circuit 1 % airflow Percentage
30023 22 Circuit 2 % airflow Percentage
30024 23 % line voltage chiller Percentage
30025 24 Zone temperature Temperature
30026 25 Outdoor air temperature Temperature
30027 26 Compressor A phase A % RLA Percentage
30028 27 Compressor A phase B % RLA Percentage
30029 28 Compressor A phase C % RLA Percentage
30030 29 Compressor B phase A % RLA Percentage
30031 30 Compressor B phase B % RLA Percentage
30032 31 Compressor B phase C % RLA Percentage
30033 32 Compressor C phase A % RLA Percentage
30034 33 Compressor C phase B % RLA Percentage
30035 34 Compressor C phase C % RLA Percentage
30036 35 Compressor D phase A % RLA Percentage
30037 36 Compressor D phase B % RLA Percentage
30038 37 Compressor D phase C % RLA Percentage
30039 38 Active current limit setpoint Percentage
30040 39 External chilled water setpoint Temperature
30041 40 External current limit setpoint Percentage
30042-30043 41-42 Compressor A running hours Hours
30044-30045 43-44 Compressor B running hours Hours
30046-30047 45-46 Compressor C running hours Hours
30048-30049 47-48 Compressor D running hours Hours
30050-30051 49-50 Compressor A starts counter None
30052-30053 51-52 Compressor B starts counter None
30054-30055 53-54 Compressor C starts counter None
30056-30057 55-56 Compressor D starts counter None
30058 57 Circuit 1 compressor suction refrigerant temperature Temperature
30059 58 Circuit 1 sat evap refrigerant temperature Temperature
30060 59 Circuit 1 sat cond refrigerant temperature Temperature
30061 60 Circuit 2 compressor suction refrigerant temperature Temperature
30062 61 Circuit 2 sat evap refrigerant temperature Temperature
30063 62 Circuit 2 sat cond refrigerant temperature Temperature
30064 63 Circuit 1 subcooled liquid refrigerant temperature Temperature
30065 64 Circuit 2 subcooled liquid refrigerant temperature Temperature
30066 65 Compressor A entering oil temperature Temperature
30067 66 Compressor B entering oil temperature Temperature
30068 67 Auxiliary temperature Temperature
30069 68 Unit tonnage tons
Analog
Inputs
4
Unit
Table 14 - Continued
