Maintenance
67BAS-SVX08D-E4
Fields description
- Equipment type: Description of the controller the PIC is configured with.
- Protocol: Active communication protocol
- Data table last update (sec): Time elapsed since Trane Equipment data
point table was refreshed
- Message sent: Number of messages the PIC transmitted
- Message received: Number of messages the PIC received
- Last message sent (sec): Time elapsed since the PIC sent the latest
message
- Last Message received (sec): Time elapsed since the PIC received the latest
message
- Number of communication failures: self-explanatory
- Last communication error (sec): Time elapsed since the last communication
error
- Last configuration error code: Description of Trane equipment installation
process
• Not Started: Configuration not started
• Waiting Service Pin: PIC device is waiting for service pin press on the
distant equipment.
• Wrong Program ID: The equipment installed does not correspond to the
configured equipment on the PIC device.
• Subnet Node Already In Use: The PIC default subnet and node
configuration is already in use by equipment on the LON network.
• Unconfigured Fail: The PIC tries to force the equipment to go to
unconfigured state and does not succeed. Unconfigure manually the
CH530 LCI-c by pressing 15 seconds on the service pin of the CH530
LCI-c board. Once done, retry to configure the PIC.
• Unconfigured Response Fail: The PIC tries to force the equipment to go
to unconfigured state and does not succeed. Unconfigure manually the
CH530 LCI-c by pressing 15 seconds on the service pin of the CH530
LCI-c board. Once done, retry to configure the PIC.
• Unconfigured Query Status Fail: The PIC tries to ask to the equipment
its configured status and the request fails.
• Address Unbound Fail: The PIC tries to unbind the equipment and does
not succeed.
• Read Memory Fail: The PIC tries to read the memory of the equipment
and does not succeed.
• Net Var Unbound Fail: The PIC tries to unbind network variables of the
equipment and does not succeed.
• Query Status Fail: The PIC tries to ask to the equipment something and
the request fails.
• Equipment Configured Fail: The equipment indicates to the PIC that the
Configuration operation has failed.
• Subnet Node Query Status Fail: The PIC tries to ask to the equipment its
subnet and node configuration and does not succeed.
• Configuration Pass:The PIC auto-install processwas successful.
Command description
- Pause: freezes the screen with current values
- Quit: exits the diagnostic tool
