Trane Precedent TSK036 Series - Page 15

RT-SVX092A-EN
15
Figure 4. A.0 cabinet – downflow airflow supply/return, through-the-base utilities
THROUGH
THE BASE
GAS PIPING
THROUGH
THE BASE
ELECTRICA
L
SUPPLY
RETURN
THROUGH THE BASE CONDENSATE
3 5/8”
92 MM
14”
356 MM
9 1/4”
235 MM
15 1/2”
394 MM
4”
102 MM
24”
610 MM
18”
457 MM
27 9/16”
701 MM
4 3/16”
106 MM
4 9/16”
116 MM
23 1/2”
597 MM
2 13/16”
71 MM
6 1/2”
165 MM
3 11/16”
94 MM
4 7/8”
124 MM
5 1/16”
128 MM
9 15/16”
253 MM
Figure 5. A.0 cabinet – horizontal airflow supply/return
3-3/4"
[95]
23-1/4"
[591]
4-3/4"
[121]
8-3/4"
[222]
14-3/4"
[375]
13-3/8"
[340]
17-1/4"
[438]
RETURN
SUPPLY
3/4-14 NPT
DRAIN CONNECTION
Dimensions and Weights
