24
RT-SVX092A-EN
Figure 22. C.0 cabinet – swing diameter for hinged door(s) option
17-3/8"
[443]
11"
[279]
35"
[890]
21-3/4"
[554]
Figure 23. A.0, B.0, and C.0 cabinets – standard economizer, manual or motorized fresh air damper
ECONOMIZER HOOD
BAROMETRIC
RELIEF HOOD
C D
B
A
Dimensions and Weights
