Table 24. Wiring diagrams (continued)
Schematic Type
Controls
Voltage
Schematic
Description
Main Unit
Symbio 700
All 12134983
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, COOLING ONLY/
ELECTRIC HEAT, STD SCCR, FORWARD CURVE FAN
Main Unit
Symbio 700
All 12134984
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, COOLING ONLY/
ELECTRIC HEAT, HIGH SCCR, FORWARD CURVE FAN
Main Unit
Symbio 700
230V 12134985
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, 2 STAGE GAS
HEAT, 230V STD SCCR, FORWARD CURVE FAN
Main Unit
Symbio 700
460V 12134986
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, 2 STAGE GAS
HEAT, 460V STD SCCR, FORWARD CURVE FAN
Main Unit
Symbio 700
230V 12134987
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, 2 STAGE GAS
HEAT, 230V HIGH SCCR, FORWARD CURVE FAN
Main Unit
Symbio 700
460V 12134988
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, 2 STAGE GAS
HEAT, 460V HIGH SCCR, FORWARD CURVE FAN
Main Unit
Symbio 700
230V 12134989
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, LOW NOX GAS
HEAT, 230V STD SCCR
Main Unit
Symbio 700
460V 12134990
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, LOW NOX GAS
HEAT, 460V STD SCCR
Main Unit
Symbio 700
230V 12134993
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, LOW NOX GAS
HEAT, 230V HIGH SCCR
Main Unit
Symbio 700
460V 12134994
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, LOW NOX GAS
HEAT, 460V HIGH SCCR
Main Unit
Symbio 700
230V 12134727
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, MOD GAS HEAT,
230V, STD SCCR
Main Unit
Symbio 700
460V/575V 12134728
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, MOD GAS HEAT,
460V/575V, STD SCCR
Main Unit
Symbio 700
All 12134921
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, COOLING ONLY/
ELECTRIC HEAT, STD SCCR
Main Unit
Symbio 700
230V 12134922
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, 2-STAGE GAS
HEAT, 230V, STD SCCR
Main Unit
Symbio 700
460V/575V 12134941
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, 2-STAGE GAS
HEAT, 460V/575V, STD SCCR
Main Unit
Symbio 700
All 12134942
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, COOLING ONLY/
ELECTRIC HEAT, HIGH SCCR
Main Unit
Symbio 700
230V 12134943
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, 2-STAGE GAS
HEAT, 230V, HIGH SCCR
Main Unit
Symbio 700
460V/575V 12134944
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, 2-STAGE GAS
HEAT, 460V/575V, HIGH SCCR
Main Unit
Symbio 700
230V 12134951
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, MOD GAS HEAT,
230V, STD SCCR
Main Unit
Symbio 700
460V/575V 12134952
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, MOD GAS HEAT,
460V/575V, STD SCCR
Main Unit
Symbio 700
230V 12134953
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, MOD GAS HEAT,
230V, HIGH SCCR
Main Unit
Symbio 700
460V/575V 12134954
SCHEMATIC; SHEET 2, POWER, SINGLE INDOOR FAN, MOD GAS HEAT,
460V/575V, HIGH SCCR
Main Unit
Symbio 700
All 12134827
SCHEMATIC; SHEET 2, POWER, DUAL INDOOR FAN, COOLING ONLY/
ELECTRIC HEAT, STD SCCR
Main Unit
Symbio 700
230V 12134828
SCHEMATIC; SHEET 2, POWER, DUAL INDOOR FAN, 2-STAGE GAS
HEAT, 230V, STD SCCR
Main Unit
Symbio 700
460V/575V 12134829
SCHEMATIC; SHEET 2, POWER, DUAL INDOOR FAN, 2-STAGE GAS
HEAT, 460V/575V, STD SCCR
