Relays and terminals on enclosure size H6
1Mains
2 Motor
3Ground
4Relays
Illustration 3.3 Enclosure Size H6
IP20, 380–480 V, 30–45 kW (40–60 hp)
IP20, 200–240 V, 15–18.5 kW (20–25 hp)
IP20, 525–600 V, 22–30 kW (30–40 hp)
Relays and terminals on enclosure size H7
1Mains
2Relays
3Ground
4Motor
Illustration 3.4 Enclosure Size H7
IP20, 380–480 V, 55–75 kW (70–100 hp)
IP20, 200–240 V, 22–30 kW (30–40 hp)
IP20, 525–600 V, 45–55 kW (60–70 hp)
