28 RCDA-SVN002C-EN
Component Locations
Table 19. Global connection component index
Device Part Number Description
3LL1 VARIABLE EVAPORATOR REFRIGERANT LIQUID LEVEL SENSOR, CIRCUIT 1
3PT1 X13790348080 SUCTION REFRIGERANT PRESSURE TRANSDUCER, CIRCUIT 1, COMPRESSOR 1A
3PT2 X13790348080 CONDENSER REFRIGERAND PRESSURE TRANSDUCER, CIRCUIT 1
3PT3 X13790348080 OIL PRESSURE TRANSDUCER, COMPRESSOR 1B
3PT4 X13790348080 OIL PRESSURE TRANSDUCER, COMPRESSOR 1A
3PT5 X13790348080 SUCTION REFRIGERANT PRESSURE TRANSDUCER, CIRCUIT 1, COMPRESSOR 1B
3RT1 X13650726100 OIL TEMPERATURE SENSOR, CIRCUIT 1, COMPRESSOR 1A
3RT2 X13650726100 OIL TEMPERATURE SENSOR, CIRCUIT 1, COMPRESSOR 1B
3V1 Varies
(a)
(a) Part number varies depending on unit configuration.
ELECTRONIC EXPANSION VALVE, CIRCUIT 1
4LL1 Varies(a) EVAPORATOR REFRIGERANT LIQUID LEVEL SENSOR, CIRCUIT 2
4PT1 X13790348080 SUCTION REFRIGERANT PRESSURE TRANSDUCER, CIRCUIT 2, COMPRESSOR 2A
4PT2 X13790348080 CONDENSER REFRIGERAND PRESSURE TRANSDUCER, CIRCUIT 2
4PT3 X13790348080 OIL PRESSURE TRANSDUCER, COMPRESSOR 2B
4PT4 X13790348080 OIL PRESSURE TRANSDUCER, COMPRESSOR 2A
4PT5 X13790348080 SUCTION REFRIGERANT PRESSURE TRANSDUCER, CIRCUIT 2, COMPRESSOR 2B
4RT1 X13650726100 OIL TEMPERATURE SENSOR, CIRCUIT 2, COMPRESSOR 2A
4RT2 X13650726100 OIL TEMPERATURE SENSOR, CIRCUIT 2, COMPRESSOR 2B
4V1 Varies(a) ELECTRONIC EXPANSION VALVE, CIRCUIT 2
6RT1 X13650726100 EVAPORATOR ENTERING WATER TEMPERATURE SENSOR
6RT2 X13650726100 EVAPORATOR LEAVING WATER TEMPERATURE SENSOR
6RT3 X13650726100 AMBIENT AIR TEMPERATURE SENSOR
1622-01 X19051622010 HARNESS 2Y SHORT (500mm)
1622-02 X19051622020 HARNESS 2Y LONG (1000mm)
1622-03 X19051622030 HARNESS 3Y (500mm)
1623-01 X19051623010 HARNESS EXTENSION, SHORT (1000mm)
1623-02 X19051623010 HARNESS EXTENSION, LONG (2000mm)
1625-02 X19051622010 HARNESS FEMALE TO WIRE LEADS (1000mm)
