General Information
RCDA-SVN002C-EN 9
Optional Add-On Kits
Table 9. LonTalk kit — 018800430100
Part Number Mnemonic Description Quantity
X13650845040 MOD02418 Module, COM5 Interface 1
Table 10. Generic BAS LLIDs kit — 018800050100
Part Number Mnemonic Description Quantity
X13650728070 BRD04873 Dual Low Voltage Input (ICE Making Control) 1
X13650731070 BRD04875 Analog Input/Output, External Current Limit & Ex
ternal Chilled Water Set Point 1
X13650733070 BRD04878 Dual Relay, Ice Making Status (Active or Complete) 1
X13650806050 BRD04879 Quad Relay, Unit Operating Status 1
Table 11. Efector flow switch kit — 018800070100
Part Number Mnemonic Description Quantity
X13651586010 KIT12480 Efector Flow Switch Kit 1
Efector Flow Switch Kit Components:
X13651583010 MOD02115 Module; Control for Flow Sensors 1
X13790922010 SEN0318 Sensor, Flow 1
X17311072010 ADP01332 Adapter; 1/2 NPT 1
X19052272010 CAB01408 Wire Harness; 5-in Micro DC Cable, 10m long 1
Global Connection Harness Upgrade Kits
Table 12. Global connector kit, 2 compressor units, base lengths 15, 18 or 21 ft — 018800380100
Part Number Mnemonic Description Quantity
X13790348080 TDR00354 Pressure Transducer 6
X13650726100 SEN01959 Temperature Sensor 5
X13540076010 RSN00002 Resin; Heat Conductive Compound, 4 oz. 1
KIT13723 KIT13723 4-wire Ribbon to Global Connector Adapter 15
X19051622010 CAB01146 2Y - Short Wire Harness; 1-2 Branching 500 MM +/-10MM 600V 18AWG 5
X19051622020 CAB01147 2Y - Long Wire Harness; 1-2 Branching 1000 MM +/-20MM 600V 18AWG 5
X19051622030 CAB01148 3Y Wire Harness; 1-3 Branching 500 MM +/-10MM 600V 18AWG 5
X19051623010 CAB01149 EXT-Short Wire Harness; Extension 1000 MM +/-20MM 600V 18AWG 8
X19051623020 CAB01150 EXT - Long Wire Harness; Extension 2000 MM +/-30MM 600V 18AWG 1
X19051625020 CAB01155 F to M Wire Harness; Extension 1000 MM +/-20MM 600V 20AWG 1
X19210028180 TIE00053 Tie; Wire/Cable, .06-4.0 DIA 100
Table 13. Global connector kit, 3 compressor units, base lengths 30, 36 or 39 ft — 018800390100
Part Number Mnemonic Description Quantity
X13790348080 TDR00354 Pressure Transducer 8
X13650726100 SEN01959 Temperature Sensor 6
X13540076010 RSN00002 Resin; Heat Conductive Compound, 4 oz. 1
KIT13723 KIT13723 4-wire Ribbon to Global Connector Adapter 18
X19051622010 CAB01146
Wire Harness; 1-2 Branching 500 MM +/-10MM 600V 18AWG 4
X19051622020 CAB01147 Wire Harness; 1-2 Branching 1000 MM +/-20MM 600V 18AWG 6
X19051622030 CAB01148 Wire Harness; 1-3 Branching 500 MM +/-10MM 600V 18AWG 3
X19051623010 CAB01149 Wire Harness; Extension 1000 MM +/-20MM 600V 18AWG 10
X19051623020 CAB01150 Wire Harness; Extension 2000 MM +/-30MM 600V 18AWG 9
X19051625020 CAB01155 Wire Harness; Extension 1000 MM +/-20MM 600V 20AWG 2
X19210028180 TIE00053 Tie; Wire/Cable, .06-4.0 DIA 125
