Trane Tracer AdaptiView Installation Instructions

Table 6. Back plate assembly kit — 018800350100
Part Number Mnemonic Description Quantity
507118350001 RTAC UC800 Back Plate Assembly 1
Back Plate Assembly Kit Components:
X25330033200 SCR00891 Screw; Phillips Panhead, 0.375 in, thread rolling, zinc plate 8-32 4
507118340001 Back Plate, RTAC 1
X13110674010 FUS01498 Fuse, C
lass CC FNQ-R 1A 600V 1
X13110790010 HLD00314 Fuse Holder, Class CC fuses, DIN Rail Mnt 1
X13491363010 BLK01486 DIN Rail end Stop 3
X13500224040 RAL01169 DIN Rail, 5 in 1
X13550222010 TRR00401 Transformer, Class 2, 50VA 1
X13651144010 MOD01628 Module, UC800 1
X19010309460 Wire, 14 awg, UL1230 (See ES3401001) 6.5 in
X19180041070 TER00315 Insulated Terminal, Fasten Receptacle 1
X19210028100 TIE00104 Wire Tie, Push Mount 3
General Information
8 RCDA-SVN002C-EN
Kit Components — Display Mounting Option
Table 7. Unit mount option kit — 018800360100
Part Number Mnemonic Description Quantity
507118320001 Display Enclosure Assembly 1
507119260001 Flange Head Screw, SS, 10-32 x 0.5 4
507119270001 Lock Nut, SS, 10-32 8
507119060001 Display Back Plate 1
Table 8. Arm mount option kit — 018800370100
Part Number Mnemonic Description Quantity
X45091462010 ARM00848 Arm; Gas Spring LCD Wall Mount 1
507119120001 5/16-18 x 5/8" long Stainless Sealing Cap Screw 4
507119110001 5/16-18 Stainless Nylon Locknut 4
X19051623010 CAB01149 Wire Harness Extension, 1000mm 1
