General Information
RCDA-SVN002C-EN 7
RTAC AdaptiView™ Display
Upgrade Kit Contents
UC800/TD7 Upgrade Kit
Kit Components — Standard
Table 1. TD7 kit contents — 018800330100
Part Number Mnemonic Description Quantity
X13651571010 MOD01924 Module; TD7 Display
(a)
(a)Includes screws, 7 ft ethernet cable, nameplate, Phoenix connectors, 3.25 ft. global harness
1
X19070632020 CAB01206 Sealed Ethernet Cable, 3700mm (12 ft) 1
X19051625030 CAB01534 PWR Cable from TD7 to UC800 (Connector to Pr
epped End), 78.74” 1
Table 2. USB port kit contents — 018800420100
Part Number Mnemonic Description Quantity
X19140818010 CAB01260 Cable; USB B-Port, 0.5 m Length 1
X19201118010 CAP01053 Cap; USB B-Port, Waterproof 1
Table 3. Miscellaneous kit contents — 018800340100
Part Number Mnemonic Description Quantity
507119190001 Bolt, SS, 1/4-20 x 1.25" 4
507118150001 Locknut, SS, 1/4-20, 4
507119200001 Sealing Washer, SS, 1/4, 4
X19210039 MNT00715 Cable Tie Mount Adhesive Backed - for securing cables 11
X19210028010 TIE00122 Cable Ties 0.1 x ~3.87" long 15
507118170001 Cord Grip, 3/4 NPT, Split Grommet, 1
507119210001 Cord Grip, 1/2 NPT, Split Grommet 1
507119220001 Cord Grip Nut, 3/4 NPT 1
507119230001 Cord Grip Nut, 1/2 NPT 1
507117820001 Bushing, Split, 1.25" 1
X19010309460 Single conductor cable - 14awg UL 1230 blk WIRE 8 ft
X19180041070 TER00315 Insulated Terminal, Fasten Re
ceptacle, 0.25in, 16-14AWG 4
X1918
0041050 TER01160 Insulated Terminal, Fasten Receptacle, 0.25in, 22-18AWG 3
5
07119240001 Hole plug, 11/16” 1
507119250001 Hole plug, 1/8” 4
X25330033030 SCR01401
Screw; Phillips Panhead 0.5 inc
h, t
hread rolling,
zinc plate 4-40
1
Table 4. Literature kit contents — 018800410100
Part Number Mnemonic Description Quantity
RCDA-SVN002*-EN RTAC Controls Upgrade KIT IOM, UC800 1
SRV-SVU004*-EN RTAC Controls Operation Guide 1
RTAC-SVP001*-EN RTAC Integration Guide 1
BAS-SVP031*-EN Programming Guide 1
X39003841010 ServiceFirst Label 1
507119170001 Schematic, RTAC Controls Upgrade, UC800 1
Table 5. Nameplate — 018503790100
Part Number Mnemonic Description Quantity
X39001352010 Serialized Nameplate 1
