Wiring
RCDA-SVN002C-EN 35
Important: Optional efector flow switch connection at 1TB5 is 115V.
Figure 41. RTAC UC800/Tracer AdaptiView upgrade schematic (continued)
NOTES: 1. 1F25 FUSE: 1 AMP, CLASS CC FNQ-R, 600V
OPTIONAL EFFECTOR FLOW SWITCH
1U11
DUAL HIGH
VOLTAGE INPUT
J11
WB5
J1
2 1 2 1
17
2
18
3
19
1
20
4
21
5
57 8 4 12
1TB5; 9-16
1TB5; 1-8
EVAPORATOR WATER
FLOW DETECTOR
(FIELD INSTALLED)
