Figure 43. Global harness wiring diagram — 2 compressor unit, 18 foot base
1625-02
TO CONTROL PANEL
POWER SUPPLY 1U2-J3
1622-02
4PT2
1623-01
1622-03
4RT1
1623-01
4PT3
1622-01
3LL1
1622-03
1623-01
3PT1
6RT3
1622-03
1623-01
4V1
3V1
1622-02
4PT1
1622-03
6RT2
1623-01
6RT1
1622-02
4LL1
1622-03
1623-02
3PT2
1623-01
3PT3
3RT1
Wiring
RCDA-SVN002C-EN 37
