Chapter 13 Installing EX2 expansion modules
68 CNT-SVN01C-EN
Figure 40. Dimensions and clearances for frame-mount EX2
Figure 41. Dimensions and clearances for metal-enclosure EX2
1 in.
(25 mm)
1 in.
(25 mm)
4 in.
(102 mm)
4 in.
(102 mm)
5.625 in.
(143 mm)
6.31 in.
(160 mm)
4 in.
(102 mm)
6.875 in.
(175 mm)
Clearances
Dimensions
5.375 in. (137 mm)
2 in. (51 mm)
1 in.
(25 mm)
1 in.
(25 mm)
2 in.
(51 mm)
2 in.
(51 mm)
9 in.
(229 mm)
10.37 in.
(263 mm)
width with
cover
2.25 in.
(58 mm)
1 in.
(25 mm)
6.5 in.
(165 mm)
10.25 in.
(260 mm)
width without cover
7 in.
(178 mm)
9 in.
(229 mm)
Clearances
Dimensions
24 in.
(610 mm)
1.875 in.
(48 mm)
0.28 in.
(7 mm)
