Overview
Device Inputs/Outputs
Below is a list of device inputs and outputs.
• A twisted/shielded communication link
• Zone sensor
• Occupancy sensor (optional)
• Discharge Air Temperature (DAT) and/or Supply Air Temperature (SAT)
•CO
2
sensor
• 24 Vac, Class II power
In addition to the points used for the VAV application, the spare inputs and outputs on the UC400
controller may be used for ancillary control and programmed using Tracer TU Tracer Graphical
Programming 2 (TGP2).
Note: For more information on wiring spare points, refer to the Tracer UC400 Programmable
Controller Installation, Operation, and Maintenance Manual (BAS-SVX20).
Analog Inputs
• AI1;
– Space temperature; thermistor: 10k  @77°F (25°C)
– Range: 32°F to 122°F (0°C to 50°C)
•AI2;
– Space setpoint; potentiometer: 1k 
– Range: from 50°F to 90°F (10°C to 32.2°C), */** (thumbwheel) functionality supported
• AI3;
–Spare
• AI4;
– Discharge air temperature: 10k  @77°F (25°C)
– Range: from -40°F to 212°F (-40°C to 100°C)
• AI5;
– Supply air temperature: 10k  @77°F (25°C)
– Range: from -40°F to 212°F (-40°C to 100°C)
Universal Inputs
• UI1;
–Spare, but recommended for relative humidity
– Resistive/thermistor inputs: 0-10 Vdc inputs or 4-20 mA inputs
– Current Mode Impedance: 200 , Voltage Mode Impedance: 10k  minimum
• UI2;
– Provided point for CO
2
– Resistive/thermistor inputs: 0-10 Vdc inputs or 4-20 mA inputs
– Current Mode Impedance: 200 , Voltage Mode Impedance: 10k  minimum

Trane Tracer UC400 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°F to 158°F (-40°C to 70°C)
Enclosure Rating	IP20
Controller Type	Programmable
Communication Protocol	BACnet MS/TP
Power Supply	24 VAC
Power Consumption	10 VA
Humidity Range	5% to 90% RH non-condensing
Supply Voltage	24 VAC/VDC
