CNT-SVX04A-EN
Binary outputs
20
Table 14 Four-pipe heat/cool valve control
Table 15 Four-pipe heat/cool changeover valve control
J1-1 Fan high
J1-2 Fan medium/Exhaust fan
J1-3 Fan low
J1-4 (Key)
J1-5 Cool—open
J1-6 Cool—close
J1-7 Not used
J1-8 Not used
J1-9 Heat—open
J1-10 Heat—close
J1-11 Outdoor air damper—open
J1-12 Outdoor air damper—close
TB4-1 Generic/Baseboard heat output
TB4-2 24 VAC
J1-1 Fan high
J1-2 Fan medium/Exhaust fan
J1-3 Fan low
J1-4 (Key)
J1-5 Heat/cool changeover—open
J1-6 Heat/cool changeover—close
J1-7 Not used
J1-8 Not used
J1-9 Heat—open
J1-10 Heat—close
J1-11 Outdoor air damper—open
J1-12 Outdoor air damper—close
TB4-1 Generic/Baseboard heat output
TB4-2 24 VAC
