Binary outputs
CNT-SVX04A-EN
21
Table 16 DX cooling control
Table 17 Two-pipe heating valve control with DX cooling
J1-1 Fan high
J1-2 Fan medium/Exhaust fan
J1-3 Fan low
J1-4 (Key)
J1-5 Cool—DX
J1-6 Not used
J1-7 Not used
J1-8 Not used
J1-9 Not used
J1-10 Not used
J1-11 Outdoor air damper—open
J1-12 Outdoor air damper—close
TB4-1 Generic/Baseboard heat output
TB4-2 24 VAC
J1-1 Fan high
J1-2 Fan medium/Exhaust fan
J1-3 Fan low
J1-4 (Key)
J1-5 Cool—DX
J1-6 Not used
J1-7 Not used
J1-8 Not used
J1-9 Heat—Open
J1-10 Heat—Close
J1-11 Outdoor air damper—open
J1-12 Outdoor air damper—close
TB4-1 Generic/Baseboard heat output
TB4-2 24 VAC
