Dimensions and Weights
Table 2. Low vertical fan-coil component data
Unit Size 03 04 06
Coil Data
Face Area — ft
2
(cm
2
) 1.1 (1020) 1.6 (1490) 2.1 (1950)
L x D x H — in. (cm)
2-Row 20 x 1.7 x 8 (51 x 4 x 20) 29.5 x 1.7 x 8 (75 x 4 x 20) 38 x 1.7 x 8 (97 x 4 x 20)
3-Row 20 x 2.6 x 8 (51 x 7 x 20) 29.5 x 2.6 x 8 (75 x 7 x 20) 38 x 2.6 x 8 (97 x 7 x 20)
Volume — gal (L)
1-Row (Heat) 0.08 (0.30) 0.11 (0.42) 0.14 (0.53)
2-Row 0.15 (0.57) 0.22 (0.83) 0.28 (1.06)
3-Row 0.23 (0.87) 0.33 (1.25) 0.42 (1.59)
Fins/ft
2-Row 144 (4.7) 144 (4.7) 144 (4.7)
3-Row 144 (4.7) 144 (4.7) 144 (4.7)
Fan/Motor Data
Fan Quantity 1 1 1
Size — Dia”x Width” (cm) 5 x 23 (13 x 59) 5 x 32 (13 x 83) 5 x 41 (13 x 105)
Motor Quantity 1 1 1
Filter Data
1” (2.5 cm) TA
Quantity 1 1 1
Size — in. (cm) 8-7/8 x 24-1/8 (23 x 61) 8-7/8 x 33-5/8 (23 x 85) 8-7/8 x 42-1/8 (23 x 107)
