Trane UniTrane - Duct Connections

52 UNT-SVX07B-EN
Installation—Controls
Control sensor options include both unit-mounted (factory-installed) and wall-mounted sensors.
Installation instructions for the wall-mounted sensors are provided in this chapter.
General Information
Control Options (Including Factory-Installed)
Tracer ZN010 Options Tracer ZN510 and ZN520 Options
Unit-mounted zone sensor:
Digit 30 = E and Digit 31 = V
Wall-mounted zone sensor:
Digit 30 = F or G and Digit 31 = 1
Wall-mounted zone sensor:
Digit 30 = E and Digit 31 = W
Wall-mounted zone sensor:
Digit 30 = F or G and Digit 31 = 2
Split-mounted zone sensor, unit-mounted fan mode and
wall-mounted setpoint dial:
Digit 30 = E and Digit 31 = X
Split-mounted zone sensor, unit-mounted fan mode and
wall-mounted setpoint dial:
Digit 30 = F or G and Digit 31 = Y
Unit-mounted zone sensor:
Digit 30 = F or G and Digit 31 = Z
X13790843-01
X13511530-01 (wall)
X13651467-02 (comm)
X13790841-01
X13790842-01 (wall)
X13651467-02 (comm)
X13511529-01 (wall)
X13790849-01 (unit)
X13511527-01 (wall)
X13790849-01 (unit)
X13651467-02 (comm)
X13790844-01
