Trane UniTrane Installation, Operation And Maintenance Instructions

UNT-SVX07B-EN 65
Installation—Electrical
06 208/60/1 2 2.3 10.9 3.3 15.9
240/60/1 2 3.0 12.5 4.5 18.8
277/60/1 2 3.0 10.9 4.5 16.3
208/60/3 3 2.3 6.3 3.3 9.2
240/60/3 3 3.0 7.3 4.5 10.9
480/60/3 4 3.0 3.7 4.5 5.5
08 208/60/1 2 2.3 10.9 3.3 15.9 4.5 21.7
240/60/1 2 3.0 12.5 4.5 18.8 6.0 25.0
277/60/1 2 3.0 10.9 4.5 16.3 6.0 21.7
208/60/3 3 2.3 6.3 3.3 9.2 4.5 12.5
240/60/3 3 3.0 7.3 4.5 10.9 6.0 14.5
480/60/3 4 3.0 3.7 4.5 5.5 6.0 7.3
10 208/60/1 2 2.3 10.9 3.3 15.9 5.7 27.5
240/60/1 2 3.0 12.5 4.5 18.8 7.5 31.3
277/60/1 2 3.0 10.9 4.5 16.3 7.5 27.1
208/60/3 3 2.3 6.3 3.3 9.2 5.7 15.9
240/60/3 3 3.0 7.3 4.5 10.9 7.5 18.1
480/60/3 4 3.0 3.7 4.5 5.5 7.5 9.1
12 208/60/1 2 2.3 10.9 3.3 15.9 6.6 31.8
240/60/1 2 3.0 12.5 4.5 18.8 9.0 37.5
277/60/1 2 3.0 10.9 4.5 16.3 9.0 32.5
208/60/3 3 2.3 6.3 3.3 9.2 6.6 18.4
240/60/3 3 3.0 7.3 4.5 10.9 9.0 21.7
480/60/3 4 3.0 3.7 4.5 5.5 9.0 10.9
Note: All data based on individual units. Electric heat will operate only with fan at high speed.
Table 14. Force-Flo two-stage electric heat
Unit Size Volts Hz Phase Wires 1st Stage kW Total kW Total amps/ph
02 208 60 1 2 0.8 2.3 10.9
240 1 2 1.0 3.0 12.5
277 1 2 1.0 3.0 10.9
208 3 3 0.8 2.3 6.3
240 3 3 1.0 3.0 7.3
480 3 4 1.0 3.0 3.7
03 208 60 1 2 1.5 4.5 21.7
240 1 2 2.0 6.0 25.0
277 1 2 2.0 6.0 21.7
208 3 3 1.5 4.5 12.6
240 3 3 2.0 6.0 14.5
480 3 4 2.0 6.0 7.3
Table 13. Force-Flo single stage, low kW electric heat (continued)
Unit Size Voltage # Wires kW amps/ph kW amps/ph kW amps/ph
