UNT-SVX07B-EN 79
Controls Interface
Sensor operating temperature 32ºF to 122ºF (0ºC to 50ºC)
Receiver operating temperature -40ºF to 158ºF (-40ºC to 70ºC)
Storage temperature -40ºF to 185ºF (-40ºC to 85°C)
Storage and operating humidity range 5% to 95%, non-condensing
Accuracy 0.5°F over a range of 55ºF to 85°F (12.8ºC to 29.4°C)
Resolution 0.125ºF over a range of 60ºF to 80ºF (15.56ºC to 26.67°C)
0.25ºF when outside this range
Setpoint functional range (WDS only) 50ºF to 89.6ºF (10ºC to 32ºC)
Receiver voltage 24 V nominal ac/dc ±10%
Receiver power consumption <1 VA
Housing Polycarbonate/ABS blend, UV protected, UL 94-5VA
flammability rating, suitable for application in a plenum
Mounting 3.24 in (8.26 cm) for 2 mounting screws (supplied)
Sensor battery (2) AA, 1.5 V, 2800 mAh, lithium, 5-year life, UL listed
Range
(a)
Open range: 2,500 ft (762 m) (packet error rate = 2%)
Usable: 200 ft (61 m)
Typical: 75 ft (23 m)
Output power 100 mW
Radio frequency 2.4 GHz (IEEE Std 802.15.4-2003 compliant)
(2405 to 2480 MHz, 5 MHz spacing)
Radio channels 16
Address range 000 to 999
Minimum time between transmissions 30 seconds
Maximum time between transmissions 15 minutes
(a)Range values are estimated transmission distances for satisfactory operation. Actual distance is job specific and must be
determined during site evaluation.
