Trane UniTrane Installation, Operation And Maintenance Instructions

8 UNT-SVX07B-EN
Model Number Descriptions
Digits 21, 22, 23 — Electric Heat
kW — ( ) = 208 V Derate
000= No Electric Heat
010 = 1.0 kW (0.75 kW)
015 = 1.5 kW (1.1 kW)
020 = 2.0 kW (1.5 kW)
025 = 2.5 kW (1.9 kW)
030 = 3.0 kW (2.3 kW)
040 = 4.0 kW (3.0 kW)
050 = 5.0 kW (3.8 kW)
060 = 6.0 kW (4.5 kW)
070 = 7.0 kW (5.3 kW)
080 = 8.0 kW (6.0 kW)
100 = 10.0 kW
Digit 24 — Reheat Coil
0=None
A = Steam Coil
B = Hot Water Coil
D = High Capacity Hot Water Coil
Digit 25 — Disconnect Switch
0=None
D = Disconnect Switch
Digit 26 — Filter
0=None
1 = 1” Throwaway Filter
2 = 1” Throwaway MERV 8 Filter
3 = 1” Throwaway, 1 Extra
4 = 1” Throwaway MERV 8, 1 Extra
5 = 1” Throwaway, 2 Extras
6 = 1” Throwaway MERV 8, 2 Extras
7 = 1” Throwaway, 3 Extras
8 = 1” Throwaway MERV 8, 3 Extras
Digit 27 — Main Control Valve
0=None
A = 2-Way, 2-Position, NO (30 psig)
B = 3-Way, 2-Position, NO (28 psig)
C = 2-Way, 2-Position, NC (30 psig)
D = 3-Way, 2-Position, NC (20 psig)
E = 2-Way, 2-Position, NO (50 psig)
F = 3-Way, 2-Position, NO (28 psig)
G = 2-Way, 2-Position, NC (50 psig)
H = 3-Way, 2-Position, NC (28 psig)
J = 2-Way, Modulating, 0.6 Cv
(60 psig)
K = 3-Way, Modulating, 0.6 Cv
(60 psig)
L = 2-Way, Modulating, 1.1 Cv
(60 psig)
M = 3-Way, Modulating, 1.1 Cv
(60 psig)
N = 2-Way, Modulating, 2.3 Cv
(60 psig)
P = 3-Way, Modulating, 2.7 Cv
(60 psig)
Q = 2-Way, Modulating, 3.3Cv
(60 psig)
R = 3-Way, Modulating, 3.8 Cv
(60 psig)
X = Field-supplied, NO
Y = Field-supplied, NC
Z = Field-supplied 3-Wire Modulating
Digit 28 — Auxiliary Control
Valve
0=None
A = 2-Way, 2-Position, NO (30 psig)
B = 3-Way, 2-Position, NC (28 psig)
C = 2-Way, 2-Position, NC (30 psig)
D = 3-Way, 2-Position, NC (20 psig)
E = 2-Way, 2-Position, NO (50 psig)
F = 3-Way, 2-Position, NO (28 psig)
G = 2-Way, 2-Position, NC (50 psig)
H = 3-Way, 2-Position, NC (28 psig)
J = 2-Way, Modulating, 0.6 Cv
(60 psig)
K = 3-Way, Modulating, 0.6 Cv
(60 psig)
L = 2-Way, Modulating, 1.1 Cv
(60 psig)
M = 3-Way, Modulating, 1.1 Cv
(60 psig)
N = 2-Way, Modulating, 2.3 Cv
(60 psig)
P = 3-Way, Modulating, 2.7 Cv
(60 psig)
Q = 2-Way, Modulating, 3.3Cv
(60 psig)
R = 3-Way, Modulating, 3.8 Cv
(60 psig)
X = Field-supplied, NO
Y = Field-supplied, NC
Z = Field-supplied 3-Wire Modulating
Digit 29 — Piping Packages
0 = None
A = Basic Ball Valve Supply and
Return
B = Basic Ball Valve Supply/Manual
Circuit Setter
C = Basic Ball Valve Supply and
Return with Auto Circuit Setter
D = Deluxe Ball Valve Supply and
Return
E = Deluxe Ball Valve Supply/Manual
Circuit Setter
F = Deluxe Ball Valve Supply and
Return with Auto Circuit Setter
Digit 30 — Control Type
A = Fan Mode Switch
E = Tracer ZN010
F = Tracer ZN510
G = Tracer ZN520
H = Customer Supplied Thermostat
Interface (CSTI)
Digit 31 — Control Option
D = Unit-Mounted Fan Mode Switch
K = Wall-Mounted Fan Mode Switch
V = Unit-Mounted Fan Speed Switch
w/Setpoint Dial Zone Sensor
W = Wall-Mounted Fan Speed Switch
w/Setpoint Dial Zone Sensor
X = Unit-Mounted Fan Speed Switch
w/Wall-Mounted Setpoint Dial
Zone Sensor
Y = Unit-Mounted Fan Speed Switch
& Wall-Mounted Setpoint Dial
w/Comm.
Z = Unit-Mounted Fan Speed Switch,
On/Cancel, Setpoint Dial
w/ Comm.
1 = Wall-Mounted On/Cancel
w/ Comm.
2 = Wall-Mounted Fan Speed Switch,
Setpoint Dial, On/Cancel
w/ Comm.
0 = Without Control Option
3 = Unit-Mounted Low Voltage Fan
Speed Switch (Off /Hi /Med /Low)
4 = Wall-Mounted Digital Zone
Sensor (OALMH, Setpoint,
On/Cancel, Comm Jack)
5 = Wall-Mounted Digital Zone
Sensor (On/Cancel, Comm Jack)
6 = Wireless Zone Sensor
7 = Wireless Display Sensor, Unit-
Mounted Receiver
Digit 32 - IAQ Options
0 = Without IAQ Options
1 = Dehumidification
4 = Dehumidification w/ Sensor
Digits 33, 34 —Future Control
Functions
Digit 35 — Control Function #3
0 = None
2 = Condensate Overflow Detection
