TRENDnet TEW-653AP User Manual

Specifications
Hardware
Standards
IEEE802.3(10Base‐T),IEEE802.3u(100Base‐TX),IEEE802.11b,IEEE
802.11g,IEEE802.11n(draft2.0),802.3af
Interface
1x10/100MbpsAuto‐MDIXPoELANport
LEDIndicators
Power/Status,LAN,WLAN
Button Resetbutton–restoresfactorydefaultsettings
PowerSupply
ActiveEthernet(PoweroverEthernet,IEEE802.3af)‐48VDC/0.375A
Poweradapter12V/1A
PowerConsumption
6watts(max)
Dimensions
(Diameter/Height)
120mm(4.72in.)/50mm(1.97in)
Weight
280g(9.87oz)
Temperature
Operating:0°~45°C(32°~113°F)
Storage:‐20°C~70°C(‐4°~158°F)
Humidity 5%~95%typical(non‐condensing)
Certifications
CE,FCC
Wireless
ModuleTechnique
OFDM:BPSK,QPSK,16‐QAM,64‐QAM
DBPSK,DQPSK,CCK
Modes AccessPoint,WDSBridge,UniversalRepeater
Antenna 4dBiSmartInternalAntenna
Frequency 2.412~2.472GHz
Management WebBrowser(HTTP);SNMPv1,v2c
DataRate(AutoFallback)
802.11n:upto300Mbps
802.11g:upto54Mbps
802.11b:upto11Mbps
OutputPower
802.11n:18dBm(typical)@300Mbps
802.11g:18dBm(typical)@54Mbps
802.11b:17dBm(typical)@11Mbps
ReceivingSensitivity
802.11n:‐79dBm@MCS8/‐61dBm@MCS15
802.11g:‐92@6Mbps/‐72dBm@54Mbps
802.11b:‐93dBm@1Mbps/‐89dBm@11Mpbs
Encryption
64/128/152‐bit(WEP),WPA‐PSK/WPA2‐PSK,WPA/WPA2‐RADIUS,WLANL2
isolation(APMode)
Channels 1‐11(FCC),1‐13(ETSI)
