Modem Router Installation
Before you Install
Many Internet Service Providers (ISPs) allow your modem router to connect to the
Internet without verifying the information fields listed below. Skip this section for now
and if your modem router cannot connect to the Internet using the standard installation
process, come back to this page and contact your ISP to verify required ISP specification
fields listed below.
General ADSL Parameters
VCI: ____
VPI: ____
MTU: ________
Data Encapsulation (LLC/VCMux) : _________
Schedule Type (UBR/CBR/VBR/GFR): _______
VLAN Tag (If required by your ISP): _________
ADSL Connection Types:
1. Ethernet over ATM (RFC 1483 Bridged) with NAT
• 1a. Obtain IP Address Automatically (Dynamic IP Address)
Host Name (Optional) ______________________
ISP registered Mac Address or Clone MAC address (Optional)___:___:___:___:___:___
• 1b. Fixed IP address (Static IP Address)
WAN IP Address: _____. _____._____._____ (e.g. 215.24.24.129)
WAN Subnet Mask: _____. _____._____._____
WAN Gateway IP Address: _____. _____._____._____
Primary DNS Server Address: _____. _____._____._____
Secondary DNS Server Address: _____. _____._____._____
2. IP over ATM (RFC 1483 Routed)
• 2a. Obtain IP Address Automatically (Dynamic IP Address)
Host Name (Optional) ______________________
ISP registered Mac Address or Clone MAC address (Optional)___:___:___:___:___:___
• 2b . Fixed IP address (Static IP Address)
WAN IP Address: _____. _____._____._____ (e.g. 215.24.24.129)
WAN Subnet Mask: _____. _____._____._____
WAN Gateway IP Address: _____. _____._____._____
Primary DNS Server Address: _____. _____._____._____
Secondary DNS Server Address: _____. _____._____._____
3. PPP over ATM (PPPoE)
• 3a. PPPoE to obtain IP automatically
Account/User Name: _________
Password: ________________
• 3b. PPPoE with a fixed IP address
User Name: _________
Password: ________________
Verify Password: ________________
IP Address: ____. _____._____._____ (e.g. 215.24.24.129)
Primary DNS Server Address: _____. _____._____._____
Secondary DNS Server Address: _____. _____._____._____
4. PPP over Ethernet (PPPoA)
• 4a. PPPoA to obtain IP automatically
Account/User Name: _________
Password: ________________
• 4b. PPPoA with a fixed IP address
User Name: _________
Password: ________________
Verify Password: ________________
IP Address: ____. _____._____._____ (e.g. 215.24.24.129)
Primary DNS Server Address: _____. _____._____._____
Secondary DNS Server Address: _____. _____._____._____
