Frequency
• 2.412 - 2.472GHz
• 5.180 – 5.825GHz
Modulation
• 802.11b: CCK, DQPSK, DBPSK
• 802.11a/g: OFDM with BPSK, QPSK and 16/64-QAM
• 802.11n: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM with OFDM
• 802.11ac: OFDM with BPSK, QPSK and 16/64/256-QAM
Media Access Protocol
• CSMA/CA with ACK
Antenna Gain
• 2.4GHz: 2 x 4.03 dBi (max.) / 5GHz: 4 x 5.64 dBi internal antennas
Receiving Sensitivity
• 802.11a: -73 dBm (typical) @ 54Mbps
• 802.11b: -90 dBm (typical) @ 11Mbps
• 802.11g: -76 dBm (typical) @ 54Mbps
• 802.11n (2.4GHz): -89 dBm (typical) @ 300Mbps
• 802.11n (5GHz): -86 dBm (typical) @ 300Mbps
• 802.11ac: -83 dBm (typical) @ 867Mbps
Wireless Channels
• 2.4GHz: FCC: 1–11
• 5GHz: FCC: 36, 40, 44, 48, 149, 153, 157, 161, 165
Power
• Input: 100 – 240V AC, 50/60Hz
• Output: 12V DC, 1.5A external power adapter
• Max. Consumption: 15.12W
Operating Temperature
• 0° – 40° C (32° – 104° F)
Operating Humidity
• Max. 90% non-condensing
Certifications
• FCC
• IC
Dimensions
• 126 x 126 x 60mm (4.96 x 4.96 x 2.36 in.) per unit
Weight
• 372g (13.1 oz.) per unit
*Disclaimers*
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical
specifications. Actual data throughput and coverage will vary depending on
interference, network traffic, building materials, and other conditions. For maximum
performance of up to 867Mbps, use with an 867Mbps 802.11ac wireless adapter. For
maximum performance of up to 400Mbps, use with a 400Mbps 802.11n wireless
adapter. Multi-User MIMO (MU-MIMO) requires the use of multiple MU-MIMO enabled
wireless adapters.
