3.2 Fillomatic Pellet Transport Features
The integral hopper has a capacity of up to 125 kgs of pellets. Filling of the hopper
is carried out automatically by the Fillomatic pellet transport system.
The pellets are auger fed from the base of the hopper to the top of the drop feed
pipe where the pellets free fall into a cell wheel and down into the pellet burner.
Located in the hopper is a pellet level sensor which lets the system know when the
level of pellets has reached a low level and allows the system to re-fill automatically.
The design of he Fillomatic system means that pellets can be transported up to 45m
horizontally with a 2.4m vertical rise. For each additional 2.4m vertical rise, 10
meters must be taken off the horizontal travel.
11
Bulk Storage
Hopper
Auger
Vacuum Feed
Hose
To Next Page
