DISPLAYED POWER IN AUTOMATIC MODE
DISPLAY DESCRIPTION
P o No power (OFF state or BLOCK state) or fans at max speed in CHECK UP state
P a Variable Ignition or Stabilization Power
P 1 Power 1
P 2 Power 2
P 3 Power 3
P 4 Power 4
P 5 Power 5
P e Extinguishing, Modulation or Standby Power
ERRORS
DISPLAY DESCRIPTION
Er01
Error activation
Safety thermostat High voltage 1
Also with the system OFF
Er02 Error activation
Pressure switch (
Only with the Exhaust fan ON)
Er03 Error activation
Pellet thermostat High voltage 2
Er04 Water over-temperature
Er05 Exhaust over-temperature
Er09 Real time clock error
Er12 Ignition failed
Er13
Accidental Extinguishing for low brightness of the flame (The photo
probe reads a light under value L00 - Light OFF)
Er16 Lack of voltage
Er19 Extinguishing for Lack of Pellet
5.4 Power Display
5.5 Error Messages
