Page 22
18. Remote control of the instrument
The instrument functions are controlled externally by an ASCII code corresponding to the
3 first letters of the function. Spaces are removed. The message may be in upper or lower
case. The question mark ? implies an instrument response.
? or PRI (PRInt) requests displayed value.
CLE (CLEar) reinitialises the maximum / minimum / delta memories.
Code for external functions. (foot-pedal)
EXT1 external contact = data transmission
EXT2 external contact = display preset
EXT3 external contact = normal mode <-> diameter mode
EXT4 external contact = reference mode 1 <-> mode reference 2
EXT ? asks for current function of external contact.
Other codes
ID ?(identification) Instrument replies : SYLVAC – TRIMOS V600
IN (Inch) display unit
MM (MilliMètre) display unit
KEY0 (KEYboard) keyboard locked
KEY1 keyboard unlocked
CEN (CENterline) centerline mode
DIA (DIAmeter) diameter mode
DEL (DELta) delta mode (maximum-minimum)
NOR (NORmal) normal mode
MAX (MAXimum) maximum mode
MIN (MINimum) minimum mode
MOD ? (MODe) interrogation of the measuring mode :NOR,DIA,CEN,MIN,MAX,DEL
PRE (PREset) displays the preset value.
PRE + nombre memorises a new preset value.
PRE ? interrogates the memorised preset value.
RES2 (RESolution) Resolution 0.001mm - .00005 in
RES3 Resolution 0.01mm - .0005 in
SET ? (SETting) interrogation of general parameters :
MM/IN RES2/3 REF1/2 KEY 0/1 B0/1. B0=battery recharging.
UNI ? (UNIt) measuring unit : MM or IN
VER ? (VERsion) instrument program version : V 1.1 24.01.00
DIS…….. (DISplay) access to display i.e. : DIS1500.236 = displayed 1500.236
DISOFF exit of access display mode.
