6. Unpacking and installation
The V300, V600 and V1000 are supplied in a shock prof box.
The instrument itseff is surrounded with a protection cover.
- To unpack the instrument lay the box in a horizontal position,
Brand name visible on top, open it and take the instrument out carefully.
- Take off the protection cover.
- Insert the ruby ball (V-1).
- Unlock completely the transport safety screw (9), Screw, chromium-plated.
- Clean the instrument, especially the three point air bearings on the base.
DO NOT USE CHEMICAL PRODUCTS.
- Place the instrument on a granite surface table.
FOR FUTURE TRANSPORT KEEP THE ORIGINAL PACKING.
V.RE300/600/1000
V.REC300 (V300)
V.REC600 (V600)
V.REC1000 (V1000)
V.CA300 (V300)
TVA.CA600 (V600)
V.CA1000 (V1000)
