40 D01-060en202008 Manual nanoFlu
Annex // nanoFlu
Read / Write multiple registers (0x03 / 0x10)
The following values are in the registers:
Designation R/W Address Data type Description
Modbus slave ID RW 0 Uint16
Modbus server address of the nanoFlu.
Allowed addresses: 1…247
Measurement timeout R 1 Uint16
The time in [10-1 s] that the currently running
measurement process will still require (see
also “Trigger measurement”)
Device serial number R 10 Char[20] Serial number of the nanoFlu sensor.
Firmware version R 20 Char[10] Version number of the installed rmware.
Self-trigger activated RW 100 Bool
Indicates whether the sensor is in automatic
mode (only necessary for rst installation).
Self-trigger interval RW 101 Uint32
The measurement interval in [s] for the auto-
matic mode. Adjustable range: 1s – 86400s.
Moving average RW 103 Uint16
Number of individual measurements which are
averaged for a measurement.
Adjustable range: 1 – 25.
System date and time RW 104 Uint32
Date and time as seconds since 1 January
1998. Starts again after each power-up!
Device description RW 106 Char[64]
An unrestricted description of the sensor e.g.:
“south supply line”.
Parameter Index for o󰀨set
/ scaling
RW 400 Uint16
When setting the parameter index, an o󰀨set
or scaling factor can be set for the selected
parameter.
Parameter index of nanoFlu for each parame-
ter: 0x0000.
Activate O󰀨set/Scaling RW 401 bool Species whether o󰀨set and scaling are used.
O󰀨set RW 402 Float
Parameter o󰀨set. Formula: scaled = (calibrat-
ed – o󰀨set) * scaling
Scaling RW 404 Float
Scaling factor. Formula: scaled = (calibrated –
o󰀨set) * scaling
Available substances R 500 Uint16
Available parameters:
1 := chl-a 4 := CDOM 2 := blue
Before the registers can be read above address 1000, a measurement must be triggered.
