41D01-060en202008 Manual nanoFlu
nanoFlu // Annex
Write single register (0x06)
With the “write single register” function, instead of changing the conguration values, a single measurement
trigger is sent, in which a value ≠0 is written.
Designation Address Description
Trigger measurement 1 A single measurement is taken.
Report slave ID (0x11)
Provides the sensor designation followed by the serial number followed by the rmware version each as a
null-terminated ASCII character string.
Example:
n a n o F l u 0x00 D 2 0 0 0x00 1 . 0 . 0 0x00
Writing to the conguration registers should be done as seldom as possible and
especially not in every measuring cycle, otherwise the ash memory may be
damaged.
NOTICE
Parametername RW 603 Char[32] Name of the parameter
Temperature R 998 Float
Sensor temperature in [°C] during the last
measurement.
Concentration / scaled
concentration
R 1000/1500 Float
