Triumph Sprint ST User Manual

115
Maintenance and Adjustment
License Plate Light
Bulb Replacement
Carefully remove the rubber bulb holder
from the back of the license plate light unit
and remove the bulb.
Installation is the reverse of the removal
procedure.
Windshield Cleaning
Clean the windshield with a solution of mild
soap or detergent and lukewarm water. After
cleaning, rinse well and then dry with a soft,
lint free cloth.
If the transparency of the windshield is
reduced by scratches or oxidation which
cannot be removed, the windshield must be
replaced.
Caution
To avoid cable damage, do not pull the
bulb holder using the cables.
Caution
Ensure that the bulb holder is correctly
installed to prevent water ingress.
Caution
Products such as window cleaning fluids,
insect remover, rain repellent, scouring
compounds, gasoline or strong solvents
such as alcohol, acetone, carbon
tetrachloride, etc. will damage the
windshield. Never allow these products to
contact the windshield.

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
