Triumph Sprint ST User Manual

91
Maintenance and Adjustment
Brake Fluid Level Inspection and
Adjustment
The brake fluid level in both reservoirs must
be kept between the upper and lower level
lines (reservoir held horizontal).
Front Brake
1. Front brake fluid reservoir, upper
level line
2. Lower level line
3. Safety clip
Remove the safety clip.
Remove the reservoir cover.
Fill the reservoir to the upper level line using
new DOT 4 fluid from a sealed container.
Re-install the reservoir cover ensuring that
the diaphragm seal is correctly installed.
Re-install the safety clip.
jajc
3
1
2
Warning
If there has been an appreciable drop in
the level of the fluid in either fluid
reservoir, consult your authorized Triumph
dealer for advice before riding. Riding with
depleted brake fluid levels, or with a brake
fluid leak is dangerous and will cause
reduced brake performance potentially
leading to loss of motorcycle control and
an accident.

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
