Triumph Sprint ST User Manual

35
General Information
Starter Button
The starter button operates the electric
starter. For the starter to operate, the clutch
lever must be pulled to the handlebar.
Note:
• Even if the clutch lever is pulled to
the handlebar, the starter will not
operate if the side stand is down
and a gear is engaged.
Left Handlebar Switches
1. Headlight dimmer switch
2. Turn signal switch
3. Horn button
4. Pass button
Headlight Dimmer Switch
High or low beam can be selected with the
headlight dimmer Switch. To select high
beam, push the switch forward. To select low
beam, push the switch rearwards. When the
high beam is turned on, the high beam
indicator light will illuminate.
Note:
• A lighting on/off switch is not
fitted to this model. The headlight,
brake/tail Light and license plate
light all function automatically
when the ignition is turned to the
ON position.
Caution
Do not leave the ignition switch in the ON
position unless the engine is running as
this may cause damage to electrical
components and will discharge the battery.
ccml
4
3
2
1

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
