Triumph Sprint ST User Manual

96
Maintenance and Adjustment
Suspension Setting Chart
Note:
• These charts are only a guide.
Setting requirements may vary for
rider weight and personal
preferences. See the following
pages for instructions on how to
adjust your suspension.
Sprint ST
Sprint GT
Front Suspension Settings
The standard suspension settings provide a
comfortable ride and good handling
characteristics for general, solo riding. The
chart shows suggested settings for the front
and rear suspension.
The front suspension is adjustable for
pre-load only. The spring pre-load adjusters
are located at the top of each fork.
Note:
• The setting figures for the front
suspension are measured as the
number of adjuster rings visible
above the fork top cap.
LOADING FRONT REAR
Spring
Pre-Load †
Rebound
Damping*
Spring
Pre-Load ‡
Solo Riding 3 1.5 20
Rider and
Passenger or Rider
and Luggage
31.010
Rider, Passenger
and Luggage
30.5 0
† Adjuster rings visible above fork cap.
* Number of adjuster turns in from the fully screwed out (hard)
position.
‡ Number of clicks out from the fully screwed in position.
LOADING FRONT REAR
Spring
Pre-Load †
Rebound
Damping*
Spring
Pre-Load ‡
Solo Riding 3 1.0 30
Rider and
Passenger or Rider
and Luggage
30.2520
Rider, Passenger
and Luggage
30.25 0
† Adjuster rings visible above fork cap.
* Number of adjuster turns in from the fully screwed out (hard)
position.
‡ Number of clicks out from the fully screwed in position.
Warning
Ensure that the correct balance between
front and rear suspension is maintained.
Suspension imbalance could significantly
change handling characteristics leading to
loss of control and an accident. Refer to the
chart on the previous page for further
information or consult your dealer.
Warning
Ensure that the adjusters are set to the
same setting on both forks. Settings which
vary from left to right could significantly
change handling characteristics leading to
loss of control and an accident.

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
