Triumph Sprint ST User Manual

Specifications
123
Sprint ST Sprint GT
Ignition
Ignition System Digital Inductive Digital Inductive
Electronic Rev Limiter (r/min) 9,500 (r/min) 9,500 (r/min)
Spark Plug NGK CR9EK NGK CR9EK
Spark Plug Gap 0.027 in (0.7 mm) 0.027 in (0.7 mm)
Gap Tolerance +0.001/-0.003 min
(+0.05/-0.1 mm)
+0.001/-0.003 min
(+0.05/-0.1 mm)
Transmission
Transmission Type 6 Speed, Constant Mesh 6 Speed, Constant Mesh
Clutch Type Wet, Multi-Plate Wet, Multi-Plate
Final Drive Chain DID X-Ring Endless,
10 6 L i nk
DID X-Ring Endless,
116 L i nk
Primary Drive Ratio 1.750 (105/60) 1.750 (105/60)
Gear Ratios:
Final Drive Ratio 2.211 (19/42) 2.211 (19/42)
1st 2.733 (15/41) 2.733 (15/41)
2nd 1.947 (19/37) 1.947 (19/37)
3rd 1.545 (22/34) 1.545 (22/34)
4th 1.292 (24/31) 1.292 (24/31)
5th 1.154 (26/30) 1.154 (26/30)
6th 1.074 (27/29) 1:1 (28/28)

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
