Triumph Sprint ST User Manual

75
Maintenance and Adjustment
Engine Oil
In order for the engine, transmission, and
clutch to function correctly, maintain the
engine oil at the correct level, and change the
oil and oil filter in accordance with scheduled
maintenance requirements.
Oil Level Inspection
1. Filler
2. Filler plug/Dipstick
3. Upper marking
Note:
• An accurate indication of the level
of oil in the engine is only shown
when the engine oil is at normal
operating temperature, the
motorcycle is upright (not on the
side stand) and the filler
plug/dipstick has been fully
screwed home.
Warning
Motorcycle operation with insufficient,
deteriorated, or contaminated engine oil
will cause accelerated engine wear and
may result in engine or transmission
seizure. Seizure of the engine or
transmission may lead to sudden loss of
control and an accident.
cbnz
ccpu
3
2
1

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
