Specifications
121
SPECIFICATIONS
Sprint ST Sprint GT
Dimensions
Overall Length 83.2 in (2,114 mm) 88.9 in (2,260 mm)
Overall Width 29.3 in (745 mm) 37 in (940 mm)
Overall Height: 47.8 in (1,215 mm) 47.6 in (1,210 mm)
Wheelbase 57.4 in (1,457 mm) 61.6 (1,565 mm)
Seat Height 32.3 in (820 mm) 32.1 in (815 mm)
Weights
Wet Weight 531 lbs (241 kg) 590 lbs (268 kg)
Maximum Payload 473 lbs (215 kg) 473 lbs (215 kg)
Engine
Type In-line 3 cyl. In-line 3 cyl.
Displacement 64 cu in (1050 cc) 64 cu in (1050 cc)
Bore x Stroke 3.11 - 2.81 in (79 x
71.4 mm)
3.11 - 2.81 in (79 x
71.4 mm)
Compression Ratio 12.0:1 12.0:1
Cylinder Numbering Left to Right Left to Right
Cylinder Sequence Number 1 at left 1 at left
Firing Order 1-2-3 1-2-3
Starting System Electric Starter Electric Starter

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
