Triumph Sprint ST User Manual

51
General Information
On models equipped with ABS: Ensure
that the ABS warning light does not remain
illuminated at speeds above 6 mph (10 km/h)
when moving off (page 57).
Brake Pads: There should be more than
0.06 in (1.5 mm) of friction material
remaining on all the pads (page 88).
Brake Fluid Levels: No brake fluid leakage.
Brake fluid levels must be between the MAX
and MIN marks on both reservoirs (page 91 ).
Front Forks: Smooth action. No leaks from
fork seals (page 95).
Throttle: Throttle grip free play
0.08 - 0.12 in (2-3 mm. Ensure that the
throttle grip returns to the idle position
without sticking (page 82).
Clutch: Smooth operation and correct cable
free play (page 84).
Coolant: No coolant leakage. Check the
coolant level in the expansion tank (when the
engine is cold) (page 79).
Electrical Equipment: All lights and horn
function correctly (page 35).
Engine Stop: Stop switch turns the engine
off (page 54).
Stands: Return to the fully up position by
spring tension. Return springs not weak or
damaged (page 39).

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
