Triumph Sprint ST User Manual

61
How to Ride the Motorcycle
Note:
• When parking near traffic at night,
or when parking in a location
where parking lights are required
by law, leave the tail, license plate
and position lights on by turning
the ignition switch to P (Park).
Do not leave the switch in the P position for
long periods of time as this will discharge the
battery.
Ensure that the side stand is fully retracted
before riding off.
Warning
Do not park on a soft or on a steeply
inclined surface. Parking under these
conditions may cause the motorcycle to fall
over causing damage to property and
personal injury.
Warning
Gasoline is extremely flammable and can
be explosive under certain conditions. If
parking inside a garage or other structure,
be sure it is well ventilated and the
motorcycle is not close to any source of
flame or sparks. This includes any
appliance with a pilot light.
Failure to follow the above advice may
cause a fire resulting in damage to
property or personal injury.
Warning
The engine and exhaust system will be hot
after riding. DO NOT park where
pedestrians and children are likely to touch
the motorcycle.
Touching any part of the engine or exhaust
system when hot may cause unprotected
skin to become burnt.

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
